FAG 11208-TVH Bearing

FAG 11208-TVH bearings

Also known as : 11208-TVH

  • Inside Diameter: 40 mm
  • Outside Diameter: 80 mm
  • Width: 56 mm
  • Basic dynamic load rating: 19.4 kN
  • Basic static load rating: 6.5 kN

Inquire Now

FAG 11208-TVH Bearing

FAG 11208-TVH Bearing details

d 40 mm
D 80 mm
Bi 56 mm
B 18 mm
D1 67,3 mm
Da max 73 mm
d1 54 mm
ra max 1 mm
rmin 1,1 mm
m 0,72 kg  Mass
Cr 19400 N  Basic dynamic load rating, radial
C0r 6500 N  Basic static load rating, radial
e 0,22
Y1 2,9
Y2 4,49
Y0 3,04
Cur 400 N  Fatigue limit load, radial
nG 10100 1/min  Limiting speed
nB 8600 1/min  Reference speed

As FAG bearing distributor, Nodes bearings have FAG 11208-TVH self aligning ball bearings in stock, main dimensions to DIN 630, with extended inner ring.
