FAG 6312-C3 Bearing

FAG 6312-C3 bearings | 60x130x31mm

Also known as : 6312-C3

  • Inside Diameter: 60 mm
  • Outside Diameter: 130 mm
  • Width: 31 mm
  • Basic dynamic load rating: 89 kN
  • Basic static load rating: 52 kN

Inquire Now

FAG 6312-C3 Bearing

FAG 6312-C3 Bearing details

d 60 mm
D 130 mm
B 31 mm
D1 108,6 mm
Da max 118 mm
d1 81,3 mm
da min 72 mm
ra max 2,1 mm
rmin 2,1 mm
m 1,75 kg  Mass
Cr 89000 N  Basic dynamic load rating, radial
C0r 52000 N  Basic static load rating, radial
Cur 3500 N  Fatigue limit load, radial
nG 7900 1/min  Limiting speed
nB 6700 1/min  Reference speed
f0 13,2  Calculation factor

As FAG bearing distributor, Nodes bearings have FAG 6312-C3 deep groove ball bearings in stock, main dimensions to DIN 625-1.
