INA 30/8-2RS bearings
Also known as : 30/8-2RS
- Inside Diameter: 8 mm
- Outside Diameter: 22 mm
- Width: 11 mm
- Basic dynamic load rating: 5.1 kN
- Basic static load rating: 2.6 kN
INA 30/8-2RS Bearing
INA 30/8-2RS Bearing details
| d | 8 mm | |
|---|---|---|
| D | 22 mm | |
| B | 11 mm | |
| a | 11,2 mm | |
| D2 | 19 mm | |
| Da max | 20 mm | |
| d2 | 10,5 mm | |
| da min | 10 mm | |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| α | 25 ° | Contact angle |
| m | 0,018 kg | Mass |
| Cr | 5100 N | Basic dynamic load rating, radial |
| C0r | 2600 N | Basic static load rating, radial |
| Cur | 132 N | Fatigue limit load, radial |
| nG | 25500 1/min | Limiting speed |
As INA bearing distributor, Nodes bearings have INA 30/8-2RS angular contact ball bearings in stock.
INA 30/8-2RS bearing cross reference
FAG 30/8-B-TVH bearing
8mm x 22mm x 11mm
FAG 30/8-B-2RSR-TVH bearing
8mm x 22mm x 11mm
