INA CSXG075 Bearing

INA CSXG075 bearings

Also known as : CSXG075, KG075XP0

  • Inside Diameter: 190.5 mm
  • Outside Diameter: 241.3 mm
  • Width: 25.4 mm
  • Basic dynamic load rating: 62 kN
  • Basic static load rating: 92 kN

Inquire Now

INA CSXG075 Bearing

INA CSXG075 Bearing details

d 190,5 mm
d 7 1/2 inch
D 241,3 mm
B 25,4 mm
D1 222,5 mm
d1 209,4 mm
rmin 2 mm  min. 2 is the smallest chamfer distance and the largest permissible rounding radius on the shaft and in the housing.
m 2,77 kg  Mass
Cr 62000 N  Basic dynamic load rating, radial
C0r 92000 N  Basic static load rating, radial
nG Öl 1340 1/min  Limiting speed
With grease lubrication, the permissible value is taken as 70% of the value given in the table.

Values are valid for a combination of axial and radial loads in a ratio Fa/Fr >= 0,8.

As INA bearing distributor, Nodes bearings have INA CSXG075 thin section ball bearings in stock. Four point contact bearing, type X, for operating temperatures from -54°C to +120°C.
