INA bearing size chart

INA bearing size chart

Bearing Number Brand Principal Dimensions Type
GIR15-DOINAd:15,d2:40,l4:81mmplain bearings
GIR20-DOINAd:20,d2:53,l4:103.5mmplain bearings
GIR30-DOINAd:30,d2:73,l4:146.5mmplain bearings
GIL8-UKINAd:8,d2:24,l4:48mmplain bearings
GIL10-UKINAd:10,d2:29,l4:57.5mmplain bearings
GIL17-UKINAd:17,d2:46,l4:90mmplain bearings
GIR8-UKINAd:8,d2:24,l4:48mmplain bearings
GIR15-UKINAd:15,d2:40,l4:81mmplain bearings
GIR20-UKINAd:20,d2:53,l4:103.5mmplain bearings
GIR30-UKINAd:30,d2:73,l4:146.5mmplain bearings
GIL40-DO-2RSINAd:40,d2:92,l4:188mmplain bearings
GIL50-DO-2RSINAd:50,d2:112,l4:216mmplain bearings
GIL80-DO-2RSINAd:80,d2:180,l4:320mmplain bearings
GIR40-DO-2RSINAd:40,d2:92,l4:188mmplain bearings
GIR60-DO-2RSINAd:60,d2:135,l4:242.5mmplain bearings
GIR70-DO-2RSINAd:70,d2:160,l4:280mmplain bearings
GIL40-UK-2RSINAd:40,d2:92,l4:188mmplain bearings
GIL50-UK-2RSINAd:50,d2:112,l4:216mmplain bearings
GIL70-UK-2RSINAd:70,d2:160,l4:280mmplain bearings
GIR35-UK-2RSINAd:35,d2:82,l4:166mmplain bearings
GAL10-DOINAd:10,d2:29,l2:62.5mmplain bearings
GAL12-DOINAd:12,d2:34,l2:71mmplain bearings
GAL17-DOINAd:17,d2:46,l2:92mmplain bearings
GAR10-DOINAd:10,d2:29,l2:62.5mmplain bearings
GAR20-DOINAd:20,d2:53,l2:104.5mmplain bearings
GAR30-DOINAd:30,d2:73,l2:146.5mmplain bearings
GAL8-UKINAd:8,d2:24,l2:54mmplain bearings
GAL10-UKINAd:10,d2:29,l2:62.5mmplain bearings
GAL15-UKINAd:15,d2:40,l2:83mmplain bearings
GAL17-UKINAd:17,d2:46,l2:92mmplain bearings
GAL20-DOINAd:20,d2:53,l2:104.5mmplain bearings
GAL20-UKINAd:20,d2:53,l2:104.5mmplain bearings
GAL25-UKINAd:25,d2:64,l2:126mmplain bearings
GAR8-UKINAd:8,d2:24,l2:54mmplain bearings
GAR10-UKINAd:10,d2:29,l2:62.5mmplain bearings
GAR15-UKINAd:15,d2:40,l2:83mmplain bearings
GAR20-UKINAd:20,d2:53,l2:104.5mmplain bearings
GAL30-DOINAd:30,d2:73,l2:146.5mmplain bearings
