INA K81115-TV Bearing

INA K81115-TV bearings | 75x100x7.5mm

Also known as : K81115-TV

  • Inside Diameter: 75 mm
  • Outside Diameter: 100 mm
  • Width: 7.5 mm
  • Basic dynamic load rating: 107 kN
  • Basic static load rating: 350 kN

Inquire Now


INA K81115-TV Bearing

INA K81115-TV Bearing details

Number K81115-TV
Type Thrust roller bearings
Dc1 75 mm
Dc 100 mm
Dw 7,5 mm
Ea 97 mm
Eb 78 mm
m 0,096 kg  Mass
Ca 107000 N  Basic dynamic load rating, axial
C0a 350000 N  Basic static load rating, axial
Cua 35500 N  Fatigue limit load
nG 3300 1/min  Limiting speed
nB 1190 1/min  Reference speed
  GS81115  Allocated housing locating washer
  WS81115  Allocated shaft locating washer
  LS75100  Allocated bearing washer

As INA bearing distributor, Nodes bearings have INA K81115-TV axial cylindrical roller and cage assembly in stock. K81115-TV is single direction, suitable for combination with axial bearing washers.
