NSK 51113 Thrust Ball Bearings
Also known as : 51113
- Inside Diameter: 65 mm
- Outside Diameter: 90 mm
- Width: 18 mm
- Basic dynamic load rating: 42 kN
- Basic static load rating: 117 kN
NSK 51113 Bearing
NSK 51113 Bearing details
| model | 51113 |
|---|---|
| d | 65 mm |
| D | 90 mm |
| T | 18 mm |
| d1 | 90 mm |
| D1 | 67 mm |
| rmin. | 1.0 mm |
| Ca | 42000 N |
| C0a | 117000 N |
| Limiting speeds | 2400 min-1 (Grease) |
| Limiting speeds | 3800 min-1 (Oil) |
| da | 80 mm |
| Da | 75 mm |
| ra | 1.0 mm |
| Mass | 0.324 kg (approx.) |
As a NSK Bearing distributor, Nodes bearings have NSK 51113 thrust ball bearings in stock. more related bearings: Thrust ball bearings.
NSK 51113 bearing cross reference
SKF 51113 bearing
65mm x 90mm x 18mm
NSK 51213 bearing
65mm x 100mm x 27mm
NSK 51313 bearing
65mm x 115mm x 36mm
NSK 51413 bearing
65mm x 140mm x 56mm
NSK 53213 bearing
65mm x 100mm x 28.7mm
NSK 53313 bearing
65mm x 115mm x 39.4mm
NSK 53413 bearing
65mm x 140mm x 60.2mm
NSK 53213U bearing
65mm x 100mm x 32mm
NSK 53313U bearing
65mm x 115mm x 43mm
NSK 53413U bearing
65mm x 140mm x 65mm
