NSK angular contact ball bearings wholesaler

Nodes bearings, NSK angular contact ball bearings wholesaler, have a wide range of NSK bearings in stock. welcome inquire.

The NSK angular contact ball bearings has been designed to meet the increasingly demanding requirements of original equipment manufacturers. These bearings have a contact angle so that they can sustain significant axial loads in one direction together with radial loads. Furthermore, since an axial component is generated when a radial load is applied, these bearings are generally used in pairs, triplex sets, quadruplex sets, or multiplex sets. NSK offers one of the most comprehensive ranges of angular contact ball bearings available.

NSK angular contact ball bearings

NSK angular contact ball bearing features

  • High Quality Steel - Ultra clean steel to extend bearing life by up to 80%.
  • Advanced Grease Technology - NSK lubricants that can extend grease life and performance.
  • High Grade Balls - Quiet and smooth operation even at high speed.
  • Super Finished Raceways - Specially honed to minimise noise and improve lubricant distribution and life.
  • Contact Angle - Offered in 15, 25, 30 and 40 degree angles.
  • Cages - Available in a range of Polyamide, steel and brass cage assemblies.

NSK single-Row Angular Contact Ball Bearings

Since these bearings have a contact angle, they can sustain significant axial loads in one direction together with radial loads. Because of their design, when a radial load is applied, an axial force component is produced; therefore, two opposed bearings or a combination of more than two must be used.
Since the rigidity of single-row angular contact ball bearings can be increased by preloading, they are often used in the main spindles of machine tools, for which high running accuracy is required.

NSK double-Row Angular Contact Ball Bearings

This is basically a back-to-back mounting of two single-row angular contact ball bearings, but their inner and outer rings are each integrated into one. Axial loads in both directions can be sustained, and the capacity to sustain moments is good. This type is used as fixed-end bearings.
Their cages are pressed steel.

NSK Four-Point Contact Ball Bearings

The inner ring is split radially into two pieces. Their design allows one bearing to sustain significant axial loads in either direction.
The contact angle is 35°, so the axial load capacity is high. This type is suitable for carrying pure axial loads or combined loads where the axial loads are high.
The cages are made of machined brass.

related articles

Related numbers

NSK 7000A bearings
10mm x 26mm x 8mm
NSK 7002A bearings
15mm x 32mm x 9mm
NSK 7004A bearings
20mm x 42mm x 12mm
NSK 7005A bearings
25mm x 47mm x 12mm
NSK 7006A bearings
30mm x 55mm x 13mm
NSK 7310A bearings
50mm x 110mm x 27mm
NSK 7211A bearings
55mm x 100mm x 21mm
NSK 7212A bearings
60mm x 110mm x 22mm
