TIMKEN 204K Bearing

TIMKEN Fafnir 204K Deep groove ball bearings | 20x47x14mm

Also known as : 204K

  • Inside Diameter: 20 mm
  • Outside Diameter: 47 mm
  • Width: 14 mm
  • Basic dynamic load rating: 14.4 kN
  • Basic static load rating: 6.5 kN

Inquire Now

TIMKEN 204K Bearing

TIMKEN 204K Bearing details

Bearing Number 204K
Brand TIMKEN
Type Deep groove ball bearings
Design Units METRIC
Ball Type Steel
Bearing Weight 0.104 Kg
0.23 lb
d - Bore 20.000 mm
0.7874 in
D - Outer Diameter 47.000 mm
1.8504 in
Bearing Width 14.000 mm
0.5512 in
do - Ball Diameter 7.937500 mm
0.312500 in
Ce - Dynamic Radial Rating1 14400 N
3250 lbf
C0 - Static Radial Rating 6500 N
1460 lbf
Limiting Speed (Grease) 8960 rpm
Limiting Speed (Oil) 10450 rpm
R - Inner Ring "To Clear" Radius2 1.000 mm
0.039 in
r - Outer Ring "To Clear" Radius3 1.000 mm
0.039 in
da - Inner Ring Backing Diameter 23.900 mm
0.940 in
Da - Outer Ring Backing Diameter 40.900 mm
1.610 in

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 204K bearings in stock. Radial ball bearings consist of an inner and outer ring with a cage containing a complement of precision balls. The standard Conrad-type bearing has a deep-groove construction capable of handling radial and axial loads from either direction in versatile designs that permit relatively high-speed operation.
