TIMKEN 307W Bearing

TIMKEN Fafnir 307W Maximum Capacity Ball Bearings | 35x80x21

Also known as : 307W

  • Inside Diameter: 35 mm
  • Outside Diameter: 80 mm
  • Width: 21 mm
  • Basic dynamic load rating: 51.5 kN
  • Basic static load rating: 29 kN

Inquire Now

TIMKEN 307W Bearing

TIMKEN 307W Bearing details

Bearing Number 307W
Brand TIMKEN
Type Deep groove ball bearings
Design Units METRIC
Ball Type Steel
Bearing Weight 0.513 Kg
1.13 lb
d - Bore 35.000 mm
1.3780 in
D - Outer Diameter 80.000 mm
3.1496 in
Bearing Width 21.000 mm
0.8268 in
do - Ball Diameter 14.287500 mm
0.562500 in
Ce - Dynamic Radial Rating1 51500 N
11600 lbf
C0 - Static Radial Rating 29000 N
6550 lbf
Limiting Speed (Grease) 4350 rpm
Limiting Speed (Oil) 5220 rpm
R - Inner Ring "To Clear" Radius2 1.500 mm
0.059 in
r - Outer Ring "To Clear" Radius3 1.500 mm
0.059 in
da - Inner Ring Backing Diameter 42.900 mm
1.690 in
Da - Outer Ring Backing Diameter 71.100 mm
2.800 in

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 307W bearings in stock. Radial ball bearings consist of an inner and outer ring with a cage containing a complement of precision balls. The standard Conrad-type bearing has a deep-groove construction capable of handling radial and axial loads from either direction in versatile designs that permit relatively high-speed operation.
