TIMKEN 308K Bearing

TIMKEN Fafnir 308K Deep groove ball bearings | 40x90x23mm

Also known as : 308K

  • Inside Diameter: 40 mm
  • Outside Diameter: 90 mm
  • Width: 23 mm
  • Basic dynamic load rating: 50.6 kN
  • Basic static load rating: 25.9 kN

Inquire Now

TIMKEN 308K Bearing

TIMKEN 308K Bearing details

Bearing Number 308K
Type Deep groove ball bearings
Design Units METRIC
Ball Type Steel
Bearing Weight 0.644 Kg
1.42 lb
d - Bore 40.000 mm
1.5748 in
D - Outer Diameter 90.000 mm
3.5433 in
Bearing Width 23.000 mm
0.9055 in
do - Ball Diameter 15.87500 mm
0.62500 in
Ce - Dynamic Radial Rating1 50600 N
11400 lbf
C0 - Static Radial Rating 25900 N
5850 lbf
Limiting Speed (Grease) 4620 rpm
Limiting Speed (Oil) 5380 rpm
R - Inner Ring "To Clear" Radius2 1.500 mm
0.059 in
r - Outer Ring "To Clear" Radius3 1.500 mm
0.059 in
da - Inner Ring Backing Diameter 49.000 mm
1.930 in
Da - Outer Ring Backing Diameter 81.000 mm
3.190 in

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 308K bearings in stock. Radial ball bearings consist of an inner and outer ring with a cage containing a complement of precision balls. The standard Conrad-type bearing has a deep-groove construction capable of handling radial and axial loads from either direction in versatile designs that permit relatively high-speed operation.
