FAG 3210-BD-XL-2HRS-TVH Bearing

3210-BD-XL-2HRS-TVH FAG angular contact ball bearings

Also known as : 3210A-2RS1, 3210-B-2RSR-TVH, 3210-BD-2HRS-TVH

• Inside Diameter: 50 mm
• Outside Diameter: 90 mm
• Width: 30.2 mm
• Basic dynamic load rating: 53 kN
• Basic static load rating: 44 kN

Inquire Now

FAG 3210-BD-XL-2HRS-TVH Bearing

3210-BD-XL-2HRS-TVH FAG

Part Number	3210-BD-XL-2HRS-TVH
Brand	FAG
Description	Angular contact ball bearing 32..-BD-XL-2HRS-TVH, double row, X-life, seals, plastic cage
Replaces	3210-B-2RSR-TVH, 3210-BD-2HRS-TVH
Lubricant	GA13	Ball bearing and insert bearing grease, standard for D>62mm
Sealing	2HRS	Contact seal on both sides
Cage	TVH	solid cage made of glass-fiber reinforced polyamid PA66
Tolerance class	P6	Class6 (P6), better than PN
Axial internal clearance	CN	Group N (CN)
Dimensional	SN	Rings dimensional stabilized up to 120°
Design variant	BD	Design variant BD
Main Dimensions & Performance Data
d	50 mm	Bore diameter
D	90 mm	Outside diameter
B	30.2 mm	Width
Cr	53000 N	Basic dynamic load rating, radial
C0r	44000 N	Basic static load rating, radial
Cur	3050 N	Fatigue load limit, radial
nG	5900 1/min	Limiting speed
m	0.68 kg	Weight
Mounting dimensions
da min.	57 mm	Minimum diameter shaft shoulder
Da max	83 mm	Maximum diameter of housing shoulder
ra max	1 mm	Maximum fillet radius
Dimensions
r min.	1.1 mm	Minimum chamfer dimension
D2	82.9 mm	Caliber diameter outer ring
d2	62.8 mm	Caliber diamter inner ring
a	53.2 mm	Distance between the apexes of the pressure cones
α	30 °	Contact angle
