FAG 3305-BD-XL-2HRS-TVH Bearing

3305-BD-XL-2HRS-TVH FAG angular contact ball bearings

Also known as : 3305A-2RS1TN9

• Inside Diameter: 25 mm
• Outside Diameter: 62 mm
• Width: 25.4 mm
• Basic dynamic load rating: 31.5 kN
• Basic static load rating: 21 kN

Inquire Now

FAG 3305-BD-XL-2HRS-TVH Bearing

3305-BD-XL-2HRS-TVH FAG

Part Number	3305-BD-XL-2HRS-TVH
Brand	FAG
Description	Angular contact ball bearing 33..-BD-XL-2HRS-TVH, double row, X-life, seals, plastic cage
Replaces	3305-B-2RSR-TVH, 3305-BD-2HRS-TVH
Lubricant	GA14	Ball bearing grease, low noise, standard for D<=62mm
Sealing	2HRS	Contact seal on both sides
Cage	TVH	solid cage made of glass-fiber reinforced polyamid PA66
Tolerance class	P6	Class6 (P6), better than PN
Axial internal clearance	CN	Group N (CN)
Design variant	BD	Design variant BD
Main Dimensions & Performance Data
d	25 mm	Bore diameter
D	62 mm	Outside diameter
B	25.4 mm	Width
Cr	31500 N	Basic dynamic load rating, radial
C0r	21000 N	Basic static load rating, radial
Cur	1460 N	Fatigue load limit, radial
nG	9300 1/min	Limiting speed
m	0.349 kg	Weight
Mounting dimensions
da min	32 mm	Minimum diameter shaft shoulder
Da max	55 mm	Maximum diameter of housing shoulder
ra max	1 mm	Maximum fillet radius
Dimensions
r min	1.1 mm	Minimum chamfer dimension
D2	53.7 mm	Caliber diameter outer ring
d2	37.6 mm	Caliber diamter inner ring
a	35.4 mm	Caliber diamter inner ring
α	30 °	Contact angle
