FAG 61806 Bearing

FAG 61806 bearings

Also known as : 61806

  • Inside Diameter: 30 mm
  • Outside Diameter: 42 mm
  • Width: 7 mm
  • Basic dynamic load rating: 4.5 kN
  • Basic static load rating: 2.95 kN

Inquire Now

FAG 61806 Bearing

FAG 61806 Bearing details

d 30 mm
D 42 mm
B 7 mm
D1 38,2 mm
Da max 40 mm
d1 33,1 mm
da min 32 mm
ra max 0,3 mm
rmin 0,3 mm
m 0,027 kg  Mass
Cr 4500 N  Basic dynamic load rating, radial
C0r 2950 N  Basic static load rating, radial
Cur 149 N  Fatigue limit load, radial
nG 24500 1/min  Limiting speed
nB 11500 1/min  Reference speed
f0 14,2  Calculation factor

As FAG bearing distributor, Nodes bearings have FAG 61806 deep groove ball bearings in stock, main dimensions to DIN 625-1.

FAG 61806 bearing cross reference

FAG 62206-2RSR bearing
30mm x 62mm x 20mm
NSK 6806 bearing
30mm x 42mm x 7mm
NSK 6806ZZ bearing
30mm x 42mm x 7mm
NSK 6806VV bearing
30mm x 42mm x 7mm
SKF 61806 bearing
30mm x 42mm x 7mm
FAG 16006 bearing
30mm x 55mm x 9mm
FAG 6006 bearing
30mm x 55mm x 13mm
FAG 61906 bearing
30mm x 47mm x 9mm
FAG 6206 bearing
30mm x 62mm x 16mm
FAG 6306 bearing
30mm x 72mm x 19mm
FAG 6406 bearing
30mm x 90mm x 23mm
FAG 6006-2RSR-C3 bearing
30mm x 55mm x 13mm
