FAG 61914 Bearing

FAG 61914 bearings

Also known as : 61914

  • Inside Diameter: 70 mm
  • Outside Diameter: 100 mm
  • Width: 16 mm
  • Basic dynamic load rating: 25 kN
  • Basic static load rating: 21.2 kN

Inquire Now

FAG 61914 Bearing

FAG 61914 Bearing details

d 70 mm
D 100 mm
B 16 mm
D1 90,3 mm
Da max 95,4 mm
d1 79,7 mm
da min 74,6 mm
ra max 1 mm
rmin 1 mm
m 0,34 kg  Mass
Cr 25000 N  Basic dynamic load rating, radial
C0r 21200 N  Basic static load rating, radial
Cur 1160 N  Fatigue limit load, radial
nG 9500 1/min  Limiting speed
nB 6400 1/min  Reference speed
f0 16,4  Calculation factor

As FAG bearing distributor, Nodes bearings have FAG 61914 deep groove ball bearings in stock, main dimensions to DIN 625-1.

FAG 61914 bearing cross reference

NSK 6914 bearing
70mm x 100mm x 16mm
NSK 6914ZZ bearing
70mm x 100mm x 16mm
NSK 6914DDU bearing
70mm x 100mm x 16mm
NSK 6914VV bearing
70mm x 100mm x 16mm
SKF 61914 bearing
70mm x 100mm x 16mm
FAG 16014 bearing
70mm x 110mm x 13mm
FAG 16014-MA bearing
70mm x 110mm x 13mm
FAG 6014 bearing
70mm x 110mm x 20mm
FAG 6014-M bearing
70mm x 110mm x 20mm
FAG 6014-M-J20AA bearing
70mm x 110mm x 20mm
FAG 61814-Y bearing
70mm x 90mm x 10mm
FAG 6214 bearing
70mm x 125mm x 24mm
