FAG 694-2Z Bearing

FAG 694-2Z Deep groove ball bearing

Also known as : 694ZZ

• Inside Diameter: 4 mm
• Outside Diameter: 11 mm
• Width: 4 mm
• Basic dynamic load rating: 959 kN
• Basic static load rating: 347 kN

Inquire Now

FAG 694-2Z Bearing

Part Number	694-2Z
Brand	FAG
Catagory	Deep groove ball bearing 69..-2Z, single row, shields, steel sheet metal cage
d	4 mm, Bore diameter
D	11 mm, Outside diameter
B	4 mm, Width
Cr	959 N, Basic dynamic load rating, radial
C0r	347 N, Basic static load rating, radial
Cur	9.3 N, Fatigue load limit, radial
Limiting speed	69000 1/min
Reference speed	1/min
Weight	1.8 g
Other Dimensions
rmin	0.15 mm, Minimum chamfer dimension
D2	9.95 mm, Caliber diameter outer ring
Mounting dimensions
da min	4.8 mm, Minimum diameter shaft shoulder
Da max	10.2 mm, Maximum diameter of housing shoulder
ra max	0.15 mm, Maximum diameter of housing shoulder
Calculation factors
f0	12.4, Calculation factor

FAG 694-2Z, Deep groove ball bearing 69..-2Z, single row, shields, steel sheet metal cage.

• Sealing: 2Z, -
• Cage: JN, steel sheet metal
• Tolerance: PN, Normal (PN)
• Dimensional / heat stabilization: SN, Rings dimensional stabilized up to 120°
• Lubricant: L138, Grease (L138/customer specific)
• Radial internal clearance: CN, Group N (CN)
