INA ZL5204-DRS cam followers

INA ZL5204-DRS Stud type track rollers

Also known as : ZL5204-DRS

• D: 52 mm
• d1: 20 mm
• B: 45.3 mm
• Cr: 16.1 kN
• C0r: 10.7 kN

INA ZL5204-DRS Bearing

model	ZL5204-DRS
D	52 mm
d1	20 mm
B	45.3 mm
B1 max	25.5 mm
B2	20 mm
B4	43 mm
C	20.6 mm
C1	4 mm
d2	26.8 mm
g	M10
lg	18 mm
Crowning radius	500 mm
rmin	1 mm
Cr w	16100 N, Effective dynamic load rating as track roller (radial)
C0r w	10700 N, Effective static load rating as track roller (radial)
Cur w	550 N, Fatigue limit load
Speed	5000 1/min, Speed (with continuous operation and grease lubrication)
mass	0.25 kg

INA ZL5204-DRS bearings, INA stud type track rollers, ball bearing, double row, lip seal on one side.
