INA SL182938-XL Bearing

INA SL182938-XL roller bearings

Also known as : SL182938-XL,NCF2938V

  • Inside Diameter: 190 mm
  • Outside Diameter: 260 mm
  • Width: 42 mm
  • Basic dynamic load rating: 510 kN
  • Basic static load rating: 770 kN

Inquire Now


INA SL182938-XL Bearing

INA SL182938-XL Bearing details

model SL182938-XL
d 190 mm
D 260 mm
B 42 mm
D1 238.5 mm
d1 211.5 mm
E 244.15 mm
rmin 2 mm
s 2 mm, Axial displacement
Cr 510000 N
C0r 770000 N
Cur 117000 N, Fatigue limit load, radial
Reference speed 1030 1/min
Limiting speed 1420 1/min
mass 6.5 kg

INA SL182938-XL roller bearings, semi-locating bearing, full complement cylindrical roller set, Cylindrical roller bearings.
