NSK 6010VV Bearing

NSK 6010VV Deep groove ball bearings

Also known as : 6010VV, 6010-2RZ

• Inside Diameter: 50 mm
• Outside Diameter: 80 mm
• Width: 16 mm
• Basic dynamic load rating: 21.8 kN
• Basic static load rating: 16.6 kN

Inquire Now

NSK 6010VV Bearing

model	6010VV
d	50 mm
D	80 mm
B	16 mm
rmin.	1.0 mm
Cr	21800 N 2220 kgf
C0r	16600 N 1700 kgf
Limiting speeds	8500 min-1 (Grease)
f0	15.6 (Factor)
da min	55 mm
da max	58.5 mm
Da	75 mm
ra	1 mm
Mass	0.261 kg (approx.)

NSK 6010VV ball bearings, deep groove ball bearing, Single-Row, VV: With Two Non-Contact Sealed.
