NSK 6324ZZS Bearing

NSK 6324ZZS Deep groove ball bearings

Also known as : 6324ZZS, 6324ZZ

• Inside Diameter: 120 mm
• Outside Diameter: 260 mm
• Width: 55 mm
• Basic dynamic load rating: 207 kN
• Basic static load rating: 185 kN

Inquire Now

NSK 6324ZZS Bearing

model	6324ZZS
d	120 mm
D	260 mm
B	55 mm
rmin.	3.0 mm
Cr	207000 N 21100 kgf
C0r	185000 N 18800 kgf
Limiting speeds	2200 min-1 (Grease)
f0	13.5 (Factor)
da min	133 mm
da max	161 mm
Da	247 mm
ra	2.5 mm
Mass	12.500 kg (approx.)

NSK 6324ZZS ball bearings, deep groove ball bearing, Single-Row, ZZ: With Two ShieldedS.
