NSK 51106 Bearing

NSK 51106 thrust ball bearings

Also known as :

• Inside Diameter: 30 mm
• Outside Diameter: 47 mm
• Width: 11 mm
• Basic dynamic load rating: 20.6 kN
• Basic static load rating: 42 kN

Inquire Now

NSK 51106 Bearing

NSK bearring number	51106
d	30 mm
D	47 mm
T	11 mm
d1	47 mm
D1	32 mm
rmin.	0.6 mm
Ca	20.6 kN
C0a	42 kN
Limiting speeds	4300 min-1 (Grease)
Limiting speeds	6700 min-1 (Oil)
da	40 mm
Da	37 mm
ra	0.6 mm
Mass	0.064 kg (approx.)

NSK 51106 single-direction thrust ball bearings with flat seat, 30 x 47 x 11 mm.
