NSK NU1008 Cylindrical roller bearings
Also known as : NU1008, NU1008ML
- Inside Diameter: 40 mm
- Outside Diameter: 68 mm
- Width: 15 mm
- Basic dynamic load rating: 27.3 kN
- Basic static load rating: 29 kN
NSK NU1008 Bearing
NSK NU1008 Bearing details
| model | NU1008 |
|---|---|
| d | 40 mm |
| D | 68 mm |
| B | 15 mm |
| rmin. | 1.0 mm |
| r1 min. | 0.6 mm |
| Fw | 47 mm |
| Cr |
27300 N 2780 kgf |
| C0r |
29000 N 2950 kgf |
| Limiting speeds | 10000 min-1 (Grease) |
| Limiting speeds | 12000 min-1 (Oil) |
| db min | 44 mm |
| db max | 46 mm |
| Da | 63.0 mm |
| ra | 1.0 mm |
| rb | 0.6 mm |
| Mass | 0.223 kg (approx.) |
NSK NU1008 roller bearings, NU type, cylindrical roller bearings, single-Row.
NSK NU1008 bearing cross reference
NSK NU208EW bearing
40mm x 80mm x 18mm
NSK NU2208 bearing
40mm x 80mm x 23mm
NSK NU308EW bearing
40mm x 90mm x 23mm
NSK NU2308ET bearing
40mm x 90mm x 33mm
NSK NU408 bearing
40mm x 110mm x 27mm
FAG NU1008-XL-M1 bearing
40mm x 68mm x 15mm
NTN NU1008 bearing
40mm x 68mm x 15mm
NSK N208 bearing
40mm x 80mm x 18mm
NSK N308 bearing
40mm x 90mm x 23mm
NSK N1008 bearing
40mm x 68mm x 15mm
NSK N408W bearing
40mm x 110mm x 27mm
