NTN NU2328E bearings | 140x300x102mm
Also known as : NU2328E
- Inside Diameter: 140 mm
- Outside Diameter: 300 mm
- Width: 102 mm
- Basic dynamic load rating: 1020 kN
- Basic static load rating: 1380 kN
NTN NU2328E Bearing
NTN NU2328E Bearing details
| Part Number | NU2328E |
|---|---|
| Brand | NTN |
| Type | Cylindrical roller bearings NU type |
| Mass | 38.7 kg |
| Boundary dimensions (mm) | |
| Inner dia. (d) | 140 |
| Outer dia. (D) | 300 |
| Width (B) | 102 |
| Chamfer (rs_min) | 4 |
| Basic load ratings (kN) | |
| Dynamic (Cr) | 1020 |
| Static (Cor) | 1380 |
| Basic load ratings (kgf) | |
| Dynamic (Cr) | 104000 |
| Static (Cor) | 141000 |
| Limiting speed (min-1) | |
| Grease | 1800 |
| Oil | 2100 |
| Abutment and fillet dimensions (mm) | |
| da min | 156 |
| Da max | 284 |
| ras max | 3 |
Nodes have NTN NU2328E bearings in stock. NU2328E, single row cylindrical roller bearings (Type NU).
