SKF 6218 Bearing

SKF 6218 single row deep groove ball bearings

Also known as : 6218

  • Inside Diameter: 90 mm
  • Outside Diameter: 160 mm
  • Width: 30 mm
  • Basic dynamic load rating: 101 kN
  • Basic static load rating: 73.5 kN

Inquire Now

SKF 6218 Bearing

SKF 6218 Bearing details

model 6218
d 90 mm
D 160 mm
B 30 mm
d1 112.5 mm
D2 142.6 mm
r1,2 min. 2 mm

da min 101 mm
Da max 149 mm
ra max 2 mm

C 101 kN, Basic dynamic load rating
C0 73.5 kN, Basic static load rating
Pu 2.8 kN, Fatigue load limit
Reference speed 8500 r/min
Limiting speed 5300 r/min
kr 0.025, Calculation factor
f0 14.7, Calculation factor
Mass 2.22 kg

As SKF bearing distributor, Nodes bearings have SKF 6218 ball bearings in stock, SKF Explorer, SKF deep groove ball bearing, Single-Row.
