SKF NU 206 ECP Bearing

SKF NU 206 ECP cylindrical roller bearings

Also known as : NU 206-E-TVP2

• Inside Diameter: 30 mm
• Outside Diameter: 62 mm
• Width: 16 mm
• Basic dynamic load rating: 44 kN
• Basic static load rating: 36.5 kN

Inquire Now

SKF NU 206 ECP Bearing

Part Number	NU 206 ECP
Brand	SKF
Catagory	Cylindrical roller bearings, single row
d	30.0 mm, Bore diameter
D	62.0 mm, Outside diameter
B	16.0 mm, Width
D1	mm, Shoulder diameter of outer ring
F	37.5 mm, Raceway diameter of inner ring
r1,2 min	1.0 mm, Chamfer dimension
r3,4 min	0.6 mm, Chamfer dimension outer ring small side face
smax.	1.3 mm, Permissible axial displacement
ABUTMENT DIMENSIONS
da min	34.3 mm, Diameter of spacer sleeve
da max.	36.1 mm, Diameter of spacer sleeve
db min	39.0 mm, Diameter of shaft abutment
Da max	55.9 mm, Diameter of housing abutment
ra max	1.0 mm, Radius of fillet
rb max	0.6 mm, Radius of fillet
CALCULATION DATA
C	44.0 kN, Basic dynamic load rating
C0	36.5 kN, Basic static load rating
Pu	4.5 kN, Fatigue load limit
Reference speed	13000.0 r/min
Limiting speed	14000.0 r/min
MASS
Mass bearing	0.2 kg

SKF NU 206 ECP, Cylindrical roller bearings, single row.
P : Glass fibre reinforced PA66 cage, rolling element centred
