TIMKEN 61905-2RZ-C3 Deep Groove Ball Bearings | 25x42x9mm
Also known as : 61905-2RZ-C3
- Inside Diameter: 25 mm
- Outside Diameter: 42 mm
- Width: 9 mm
- Basic dynamic load rating: 7 kN
- Basic static load rating: 4.6 kN
TIMKEN 61905-2RZ-C3 Bearing
TIMKEN 61905-2RZ-C3 Bearing details
| Bearing Number | 61905-2RZ-C3 |
|---|---|
| Brand | TIMKEN |
| Type | Deep groove ball bearings |
| Clearance | C3 |
| Bore Size d | 25.000 mm |
| Features | Non-Contact Seals |
| Weight | 0.039 Kg |
| Outside Diameter D | 42.000 mm |
| Outside Ring Width B | 9.000 mm |
| Radius Rs min | 0.300 mm |
| Cr - Dynamic Load Rating | 7 kN |
| C0r - Static Load Rating | 4.6 kN |
| Grease Limiting Speed | 16000 rpm |
| Oil Limiting Speed | 19000 rpm |
As TIMKEN bearing distributor, Nodes bearings have TIMKEN 61905-2RZ-C3 bearings in stock. Timken 61000 thin section series have bore sizes that range from 10 to 65 mm and outside diameter sizes that range from 18 to 90mm.
TIMKEN 61905-2RZ-C3 bearing cross reference
NSK 6905ZZ bearing
25mm x 42mm x 9mm
NSK 6905 bearing
25mm x 42mm x 9mm
NSK 6905DDU bearing
25mm x 42mm x 9mm
NSK 6905VV bearing
25mm x 42mm x 9mm
SKF 61905 bearing
25mm x 42mm x 9mm
FAG 61905 bearing
25mm x 42mm x 9mm
FAG 61905-2RSR bearing
25mm x 42mm x 9mm
TIMKEN 6005-2RS bearing
25mm x 47mm x 12mm
TIMKEN 6205-2RS bearing
25mm x 52mm x 15mm
TIMKEN 6305-2RS bearing
25mm x 62mm x 17mm
TIMKEN 6005-2RS-NR bearing
25mm x 47mm x 12mm
