TIMKEN 6320M-C3 Bearing

TIMKEN 6320M-C3 Deep Groove Ball Bearings | 100x215x47mm

Also known as : 6320M-C3

  • Inside Diameter: 100 mm
  • Outside Diameter: 215 mm
  • Width: 47 mm
  • Basic dynamic load rating: 173 kN
  • Basic static load rating: 140.2 kN

Inquire Now


TIMKEN 6320M-C3 Bearing

TIMKEN 6320M-C3 Bearing details

Bearing Number 6320M-C3
Brand TIMKEN
Type Deep groove ball bearings
Clearance C3
Bore Size d 100.000 mm
Features Open With Brass Cage
Weight 8.540 Kg
Outside Diameter D 215.000 mm
Outside Ring Width B 47.000 mm
Radius Rs min 3.000 mm
Cr - Dynamic Load Rating 173 kN
C0r - Static Load Rating 140.2 kN
Grease Reference Speed 4400 rpm
Oil Reference Speed 6200 rpm

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 6320M-C3 bearings in stock. Deep groove ball bearings are available in a variety of sizes and are the most popular of the rolling bearings. This type of bearing supports radial load and a small degree of axial load in both directions simultaneously.

TIMKEN 6320M-C3 bearing cross reference

NSK 6320 bearing
100mm x 215mm x 47mm
NSK 6320ZZ bearing
100mm x 215mm x 47mm
NSK 6320DDU bearing
100mm x 215mm x 47mm
NSK 6320VV bearing
100mm x 215mm x 47mm
SKF 6320 bearing
100mm x 215mm x 47mm
FAG 6320 bearing
100mm x 215mm x 47mm
FAG 6320-J20AA bearing
100mm x 215mm x 47mm
FAG 6320-J20AB bearing
100mm x 215mm x 47mm
FAG 6320-M bearing
100mm x 215mm x 47mm
FAG 6320-M-J20AA bearing
100mm x 215mm x 47mm
FAG 6320-2RSR bearing
100mm x 215mm x 47mm
TIMKEN 6020-2RS bearing
100mm x 150mm x 24mm
