TIMKEN 6409-N Deep Groove Ball Bearings | 45x120x29mm
Also known as : 6409-N
- Inside Diameter: 45 mm
- Outside Diameter: 120 mm
- Width: 29 mm
- Basic dynamic load rating: 77.2 kN
- Basic static load rating: 45.2 kN
TIMKEN 6409-N Bearing
TIMKEN 6409-N Bearing details
| Bearing Number | 6409-N |
|---|---|
| Brand | TIMKEN |
| Type | Deep groove ball bearings |
| Clearance | C0 (Normal) |
| Bore Size d | 45.000 mm |
| Features | O.D. Groove |
| Weight | 1.550 Kg |
| Outside Diameter D | 120.000 mm |
| Outside Ring Width B | 29.000 mm |
| Radius Rs min | 2.000 mm |
| Cr - Dynamic Load Rating | 77.2 kN |
| C0r - Static Load Rating | 45.2 kN |
| Grease Reference Speed | 7200 rpm |
| Oil Reference Speed | 10000 rpm |
As TIMKEN bearing distributor, Nodes bearings have TIMKEN 6409-N bearings in stock. Deep groove ball bearings are available in a variety of sizes and are the most popular of the rolling bearings. This type of bearing supports radial load and a small degree of axial load in both directions simultaneously.
TIMKEN 6409-N bearing cross reference
SKF 6409 bearing
45mm x 120mm x 29mm
FAG 6409 bearing
45mm x 120mm x 29mm
FAG 6409-M bearing
45mm x 120mm x 29mm
TIMKEN 6009-2RS bearing
45mm x 75mm x 16mm
TIMKEN 6209-2RS-C3 bearing
45mm x 85mm x 19mm
TIMKEN 6309-2RS-C3 bearing
45mm x 100mm x 25mm
TIMKEN 6309M-2RS-C3 bearing
45mm x 100mm x 25mm
TIMKEN 6009-2RS-NR bearing
45mm x 75mm x 16mm
TIMKEN 6209-2RS-NR bearing
45mm x 85mm x 19mm
TIMKEN 6009-N bearing
45mm x 75mm x 16mm
TIMKEN 6209-N bearing
45mm x 85mm x 19mm
