TIMKEN 105RU32R3 Cylindrical Roller Bearings
Also known as : 105RU32R3
- Inside Diameter: 105 mm
- Outside Diameter: 190 mm
- Width: 65.088 mm
- Basic dynamic load rating: 471 kN
- Basic static load rating: 640 kN
TIMKEN 105RU32R3 Bearing
TIMKEN 105RU32R3 Bearing details
| Bearing Number | 105RU32R3 |
|---|---|
| Brand | TIMKEN |
| Type | Cylindrical roller bearings |
| Design Units | METRIC |
| Bearing Weight |
8.3 Kg 18.300 lb |
| Type | NU |
| Tapered Bore | N |
| d - Bore |
105.000 mm 4.1339 in |
| D - Outer Diameter |
190.000 mm 7.4803 in |
| C - Inner Ring Width |
65.088 mm 2.5625 in |
| B - Outer Ring Width |
65.088 mm 2.5625 in |
| C0 - Static Radial Rating |
640000 N 144000 lbf |
| C - Dynamic Radial Rating1 |
471000 N 106000 lbf |
| Reference Thermal Speed Rating (Grease) | 2400 |
| Reference Thermal Speed Rating (Oil)2 | 2700 |
| Cg - Geometry Factor3 | 0.1129 |
| R - Inner Ring "To Clear" Radius4 |
2.000 mm 0.100 in |
| r - Outer Ring "To Clear" Radius5 |
2.000 mm 0.100 in |
| da - Inner Ring Backing Diameter |
121.000 mm 4.800 in |
| Da - Outer Ring Backing Diameter |
175.000 mm 6.900 in |
1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.
As TIMKEN bearing distributor, Nodes bearings have TIMKEN 105RU32R3 bearings in stock.
