TIMKEN NU1056MA Bearing

TIMKEN NU1056MA Cylindrical Roller Bearings | 280x420x65mm

Also known as : NU1056MA

  • Inside Diameter: 280 mm
  • Outside Diameter: 420 mm
  • Width: 65 mm
  • Basic dynamic load rating: 754 kN
  • Basic static load rating: 1080 kN

Inquire Now


TIMKEN NU1056MA Bearing

TIMKEN NU1056MA Bearing details

Bearing Number NU1056MA
Brand TIMKEN
Type Cylindrical roller bearings
Design Units METRIC
Bearing Weight 31.000 Kg
68.100 lb
Type N
U
Tapered Bore N
d - Bore 280.000 mm
11.0236 in
D - Outer Diameter 420.000 mm
16.5354 in
C - Inner Ring Width 65.000 mm
2.5591 in
B - Outer Ring Width 65.000 mm
2.5591 in
C0 - Static Radial Rating 1080000 N
243000 lbf
C - Dynamic Radial Rating1 754000 N
170000 lbf
Reference Thermal Speed Rating (Grease) 1300
Reference Thermal Speed Rating (Oil)2 1600
Cg - Geometry Factor3 0.1543
R - Inner Ring "To Clear" Radius4 3.000 mm
0.100 in
r - Outer Ring "To Clear" Radius5 3.000 mm
0.100 in
da - Inner Ring Backing Diameter 306.400 mm
12.060 in
Da - Outer Ring Backing Diameter 384.000 mm
15.120 in

1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.

As TIMKEN bearing distributor, Nodes bearings have TIMKEN NU1056MA bearings in stock.

TIMKEN NU1056MA bearing cross reference

NSK NU1056 bearing
280mm x 420mm x 65mm
FAG NU1056-M1 bearing
280mm x 420mm x 65mm
TIMKEN 280RU30R3 bearing
280mm x 420mm x 106mm
TIMKEN 280RU30R4 bearing
280mm x 420mm x 106mm
TIMKEN 280RU51R3 bearing
280mm x 460mm x 63mm
TIMKEN 280RU91OD1268 bearing
280mm x 460mm x 123.825mm
TIMKEN 280RU91OD1268R2 bearing
280mm x 460mm x 123.825mm
TIMKEN 280RU91OD1268R3 bearing
280mm x 460mm x 123.825mm
TIMKEN 280RU91OD1268R7 bearing
280mm x 460mm x 123.825mm
TIMKEN 280RU91OE1792R3 bearing
280mm x 460mm x 123.825mm
TIMKEN 280RU92AC1112 bearing
280mm x 500mm x 165.100mm
TIMKEN 280RU92AC1112R3 bearing
280mm x 500mm x 165.100mm
