TIMKEN NUP2216EMA Bearing

TIMKEN NUP2216EMA Cylindrical Roller Bearings | 80x140x33mm

Also known as : NUP2216EMA

  • Inside Diameter: 80 mm
  • Outside Diameter: 140 mm
  • Width: 33 mm
  • Basic dynamic load rating: 208 kN
  • Basic static load rating: 245 kN

Inquire Now

TIMKEN NUP2216EMA Bearing

TIMKEN NUP2216EMA Bearing details

Bearing Number NUP2216EMA
Brand TIMKEN
Type Cylindrical roller bearings
Design Units METRIC
Bearing Weight 2.3 Kg
5.1 lb
Type N
UP
Tapered Bore N
d - Bore 80.000 mm
3.1496 in
D - Outer Diameter 140.000 mm
5.5118 in
C - Inner Ring Width 28.532 mm
1.1233 in
B - Outer Ring Width 33.000 mm
1.2992 in
C0 - Static Radial Rating 245000 N
55100 lbf
C - Dynamic Radial Rating1 208000 N
46800 lbf
Reference Thermal Speed Rating (Grease) 2600
Reference Thermal Speed Rating (Oil)2 3100
Cg - Geometry Factor3 0.0846
R - Inner Ring "To Clear" Radius4 2.000 mm
0.100 in
r - Outer Ring "To Clear" Radius5 2.000 mm
0.100 in
da - Inner Ring Backing Diameter 95.000 mm
3.800 in
Da - Outer Ring Backing Diameter 0.000 mm
0.000 in

1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.

As TIMKEN bearing distributor, Nodes bearings have TIMKEN NUP2216EMA bearings in stock.

TIMKEN NUP2216EMA bearing cross reference

SKF NUP2216ECP bearing
80mm x 140mm x 33mm
TIMKEN NJ2216EMA bearing
80mm x 140mm x 33mm
TIMKEN NU2216EMA bearing
80mm x 140mm x 33mm
TIMKEN NJ2316EMA bearing
80mm x 170mm x 58mm
TIMKEN NU2316EMA bearing
80mm x 170mm x 58mm
