TIMKEN NUP2344EMA Bearing

TIMKEN NUP2344EMA Cylindrical Roller Bearings | 220x460x145

Also known as : NUP2344EMA

  • Inside Diameter: 220 mm
  • Outside Diameter: 460 mm
  • Width: 145 mm
  • Basic dynamic load rating: 2200 kN
  • Basic static load rating: 3180 kN

Inquire Now

TIMKEN NUP2344EMA Bearing

TIMKEN NUP2344EMA Bearing details

Bearing Number NUP2344EMA
Brand TIMKEN
Type Cylindrical roller bearings
Design Units METRIC
Bearing Weight 129.00 Kg
284.40 lb
Type N
UP
Tapered Bore N
d - Bore 220 mm
8.6614 in
D - Outer Diameter 460.000 mm
18.1102 in
C - Inner Ring Width 125.100 mm
4.9252 in
B - Outer Ring Width 145.000 mm
5.7087 in
C0 - Static Radial Rating 3180000 N
715000 lbf
C - Dynamic Radial Rating1 2200000 N
495000 lbf
Reference Thermal Speed Rating (Grease) 730
Reference Thermal Speed Rating (Oil)2 800
Cg - Geometry Factor3 0.1777
R - Inner Ring "To Clear" Radius4 4.000 mm
0.200 in
r - Outer Ring "To Clear" Radius5 4.000 mm
0.200 in
da - Inner Ring Backing Diameter 240.000 mm
9.500 in
Da - Outer Ring Backing Diameter 440.000 mm
17.300 in

1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.

As TIMKEN bearing distributor, Nodes bearings have TIMKEN NUP2344EMA bearings in stock.

TIMKEN NUP2344EMA bearing cross reference

TIMKEN NU5144MA bearing
220mm x 350mm x 98.400mm
TIMKEN NU2244EMA bearing
220mm x 400mm x 108mm
TIMKEN NJ2344EMA bearing
220mm x 460mm x 145mm
TIMKEN 220RU30R3 bearing
220mm x 340mm x 90mm
TIMKEN 220RU51AB909R3 bearing
220mm x 350mm x 51mm
TIMKEN 220RU51BO132R3 bearing
220mm x 350mm x 51mm
TIMKEN 220RU91BC1738R3 bearing
220mm x 350mm x 98.400mm
TIMKEN 220RU91OO127R3 bearing
220mm x 350mm x 98.400mm
TIMKEN 220RU91R3 bearing
220mm x 350mm x 98.400mm
TIMKEN 220RU91R4 bearing
220mm x 350mm x 98.400mm
TIMKEN 220RJ51 bearing
220mm x 350.002mm x 51mm
TIMKEN 220RU51R3 bearing
220mm x 350.002mm x 51mm
