FAG 126-TVH bearings
Also known as : 126-TVH
- Inside Diameter: 6 mm
- Outside Diameter: 19 mm
- Width: 6 mm
- Basic dynamic load rating: 2.6 kN
- Basic static load rating: 0.475 kN
FAG 126-TVH Bearing
FAG 126-TVH Bearing details
| d | 6 mm | |
|---|---|---|
| D | 19 mm | |
| B | 6 mm | |
| D1 | 14,7 mm | |
| Da max | 16,6 mm | |
| d1 | 10,1 mm | |
| da min | 8,4 mm | |
| ra max | 0,3 mm | |
| rmin | 0,3 mm | |
| m | 0,0090 kg | Mass |
| Cr | 2600 N | Basic dynamic load rating, radial |
| C0r | 475 N | Basic static load rating, radial |
| e | 0,35 | |
| Y1 | 1,82 | |
| Y2 | 2,82 | |
| Y0 | 1,91 | |
| nG | 41500 1/min | Limiting speed |
| nB | 30500 1/min | Reference speed |
| Cur | 29,5 N | Fatigue limit load, radial |
As FAG bearing distributor, Nodes bearings have FAG 126-TVH self aligning ball bearings in stock, main dimensions to DIN 630.
FAG 126-TVH bearing cross reference
