FAG 32319-A Bearing

FAG 32319-A tapered roller bearings

Also known as : 32319-A, T2GD095

• Inside Diameter: 95 mm
• Outside Diameter: 200 mm
• Width: 71.5 mm
• Basic dynamic load rating: 530 kN
• Basic static load rating: 710 kN

Inquire Now

FAG 32319-A Bearing

model	32319-A
Comparative designation to DIN ISO 355	T2GD095
d	95 mm
D	200 mm
T	71.5 mm
a	49 mm
B	67 mm
C	55 mm
Ca min	8 mm
Cb min	16.5 mm
Da max	186 mm
Da min	166 mm
Db min	186 mm
d1	141 mm
da max	115 mm
db min	109 mm
r1,2 min	4 mm
r3,4 min	3 mm
ra max	4 mm
rb max	3 mm
Cr	530000 N, Basic dynamic load rating, radial
C0r	710000 N, Basic static load rating, radial
Limiting speed	3500 1/min
Reference speed	2600 1/min
Cur	80000 N, Fatigue limit load, radial
e	0.35
Y	1.74
Y0	0.96
mass	10.3 kg

Nodes bearings have FAG 32319-A roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
