FAG T7FC055-XL Bearing

FAG T7FC055-XL tapered roller bearings

Also known as : T7FC055-XL,

• Inside Diameter: 55 mm
• Outside Diameter: 115 mm
• Width: 34 mm
• Basic dynamic load rating: 152 kN
• Basic static load rating: 165 kN

Inquire Now

FAG T7FC055-XL Bearing

model	T7FC055-XL
d	55 mm
D	115 mm
T	34 mm
a	40 mm
B	31 mm
C	23.5 mm
Ca min	5 mm
Cb min	10.5 mm
Da max	101 mm
Da min	86 mm
Db min	109 mm
d1	88.8 mm
da max	65 mm
db min	72 mm
r1,2 min	3 mm
r3,4 min	3 mm
ra max	3 mm
rb max	3 mm
Cr	152000 N, Basic dynamic load rating, radial
C0r	165000 N, Basic static load rating, radial
Limiting speed	6000 1/min
Reference speed	5000 1/min
Cur	25500 N, Fatigue limit load, radial
e	0.87
Y	0.69
Y0	0.38
mass	1.59 kg

Nodes bearings have FAG T7FC055-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
