FAG T7FC065-XL Bearing

FAG T7FC065-XL tapered roller bearings

Also known as : T7FC065-XL,

• Inside Diameter: 65 mm
• Outside Diameter: 130 mm
• Width: 37 mm
• Basic dynamic load rating: 186 kN
• Basic static load rating: 211 kN

Inquire Now

FAG T7FC065-XL Bearing

model	T7FC065-XL
d	65 mm
D	130 mm
T	37 mm
a	45 mm
B	33.5 mm
C	26 mm
Ca min	5 mm
Cb min	11 mm
Da max	116 mm
Da min	98 mm
Db min	124 mm
d1	101 mm
da max	75 mm
db min	83 mm
r1,2 min	3 mm
r3,4 min	3 mm
ra max	3 mm
rb max	3 mm
Cr	186000 N, Basic dynamic load rating, radial
C0r	211000 N, Basic static load rating, radial
Limiting speed	5200 1/min
Reference speed	4450 1/min
Cur	32500 N, Fatigue limit load, radial
e	0.87
Y	0.69
Y0	0.38
mass	2.19 kg

Nodes bearings have FAG T7FC065-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
