NSK 6936 Bearing

NSK 6936 Deep groove ball bearings

Also known as : 6936, 61936

• Inside Diameter: 180 mm
• Outside Diameter: 250 mm
• Width: 33 mm
• Basic dynamic load rating: 119 kN
• Basic static load rating: 128 kN

Inquire Now

NSK 6936 Bearing

PN	6936
d	180 mm
D	250 mm
B	33 mm
rmin.	2.0 mm
Cr	119000 N 12100 kgf
C0r	128000 N 13100 kgf
Limiting speeds	2200 min-1 (Grease)
Limiting speeds	2600 min-1 (Oil)
f0	16.4 (Factor)
da min	189.0 mm
da max	198.5 mm
Da	241.0 mm
ra	2.0 mm
Mass	4.910 kg (approx.)

NSK 6936 ball bearings, deep groove ball bearing, Single-Row, Open type.
