NSK NU2305ET Cylindrical roller bearings
Also known as : NU2305ET, NU2305ECP
- Inside Diameter: 25 mm
- Outside Diameter: 62 mm
- Width: 24 mm
- Basic dynamic load rating: 57 kN
- Basic static load rating: 56 kN
NSK NU2305ET Bearing
NSK NU2305ET Bearing details
| model | NU2305ET |
|---|---|
| d | 25 mm |
| D | 62 mm |
| B | 24 mm |
| rmin. | 1.1 mm |
| r1 min. | 1.1 mm |
| Fw | 34 mm |
| Cr |
57000 N 5800 kgf |
| C0r |
56000 N 5700 kgf |
| Limiting speeds | 9000 min-1 (Grease) |
| Limiting speeds | 11000 min-1 (Oil) |
| db min | 31.5 mm |
| db max | 32 mm |
| Da | 55.5 mm |
| ra | 1.0 mm |
| rb | 1 mm |
| Mass | 0.338 kg (approx.) |
NSK NU2305ET roller bearings, NU type, cylindrical roller bearings, single-Row.
NSK NU2305ET bearing cross reference
NSK NU1005 bearing
25mm x 47mm x 12mm
NSK NU205EW bearing
25mm x 52mm x 15mm
NSK NU2205 bearing
25mm x 52mm x 18mm
NSK NU2205ET bearing
25mm x 52mm x 18mm
NSK NU305EW bearing
25mm x 62mm x 17mm
NSK NU2305 bearing
25mm x 62mm x 24mm
NSK NU405 bearing
25mm x 80mm x 21mm
FAG NU2305-E-XL-TVP2 bearing
25mm x 62mm x 24mm
SKF NU2305ECP bearing
25mm x 62mm x 24mm
NTN NU2305E bearing
25mm x 62mm x 24mm
NSK N205M bearing
25mm x 52mm x 15mm
