NSK HR30215J Tapered Roller Bearings
Also known as : HR30215J, 30215
- Inside Diameter: 75 mm
- Outside Diameter: 130 mm
- Width: 27.25 mm
- Basic dynamic load rating: 143 kN
- Basic static load rating: 182 kN
NSK HR30215J Bearing
NSK HR30215J Bearing details
| model | HR30215J |
|---|---|
| d | 75 mm |
| D | 135 mm |
| T | 27.25 mm |
| B | 25 mm |
| C | 22 mm |
| Cone rmin. | 2 mm |
| Cup rmin. | 1.5 mm |
| Cr | 143000 N |
| C0r | 182000 N |
| Limiting speeds | 2800 min-1 (Grease) |
| Limiting speeds | 3800 min-1 (Oil) |
|
ISO355 Dimensions Series approx. |
4DB |
| e | 0.44 (constant) |
| y1 | 1.4 (Axial Load Factors) |
| y0 | 0.76 (Axial Load Factors) |
| Mass | 1.43 kg (approx.) |
NSK HR30215J roller bearings, tapered roller bearing, Single-Row Metric Design.
NSK HR30215J bearing cross reference
NSK HR32215J bearing
75mm x 130mm x 33.25mm
FAG 30215-A bearing
75mm x 130mm x 27.25mm
FAG 30215-XL bearing
75mm x 130mm x 27.25mm
SKF 30215 bearing
75mm x 130mm x 27.25mm
NTN 4T-30215 bearing
75mm x 130mm x 25.0mm
NSK HR32915J bearing
75mm x 105mm x 20mm
NSK HR32015XJ bearing
75mm x 115mm x 25mm
NSK HR33015J bearing
75mm x 115mm x 31mm
NSK HR33115J bearing
75mm x 125mm x 37mm
NSK HR33215J bearing
75mm x 130mm x 41mm
NSK HR30315DJ bearing
75mm x 160mm x 40mm
