SKF GE140ES-2RS Bearing

SKF GE140ES-2RS spherical plain bearings | 140x210x90mm

Also known as : GE140ES-2RS, GE140-DO-2RS

  • Inside Diameter: 140 mm
  • Outside Diameter: 210 mm
  • Width: 90 mm
  • Basic dynamic load rating: 1080 kN
  • Basic static load rating: 5400 kN

Inquire Now

SKF GE140ES-2RS Bearing

SKF GE140ES-2RS Bearing details

number GE140ES-2RS
Type Radial spherical plain bearings
d 140 mm
D 210 mm
B 90 mm
C 70 mm
α 7 °
dk 180 mm
b 13.5 mm
b1 13.5 mm
M 6 mm
r1 min. 1 mm
r2 min. 1 mm
da min. 149 mm
da max. 155.5 mm
Da min. 180 mm
Da max. 202.5 mm
ra max. 1 mm
rb max. 1 mm
Calculation data
Basic dynamic load rating C 1080 kN
Basic static load rating C0 5400 kN
Specific dynamic load factor K 100 N/mm²
Specific static load factor K0 500 N/mm²
Material constant KM 330
Mass 11 kg

As SKF bearing distributor, Nodes bearings have SKF GE140ES-2RS spherical plain bearings in stock.

A characteristic feature of SKF steel/steel radial spherical plain bearings is the outer ring, which is intentionally fractured so that it can be sprung apart to enable the inner ring to be inserted
