SKF GE70ES-2RS Bearing

SKF GE70ES-2RS spherical plain bearings | 70x105x49mm

Also known as : GE70ES-2RS, GE70-DO-2RS

  • Inside Diameter: 70 mm
  • Outside Diameter: 105 mm
  • Width: 49 mm
  • Basic dynamic load rating: 315 kN
  • Basic static load rating: 1560 kN

Inquire Now

SKF GE70ES-2RS Bearing

SKF GE70ES-2RS Bearing details

number GE70ES-2RS
Type Radial spherical plain bearings
d 70 mm
D 105 mm
B 49 mm
C 40 mm
α 6 °
dk 92 mm
b 7.7 mm
b1 7.7 mm
M 4 mm
r1 min. 1 mm
r2 min. 1 mm
da min. 76.7 mm
da max. 77.9 mm
Da min. 92 mm
Da max. 99 mm
ra max. 1 mm
rb max. 1 mm
Calculation data
Basic dynamic load rating C 315 kN
Basic static load rating C0 1560 kN
Specific dynamic load factor K 100 N/mm²
Specific static load factor K0 500 N/mm²
Material constant KM 330
Mass 1.55 kg

As SKF bearing distributor, Nodes bearings have SKF GE70ES-2RS spherical plain bearings in stock.

A characteristic feature of SKF steel/steel radial spherical plain bearings is the outer ring, which is intentionally fractured so that it can be sprung apart to enable the inner ring to be inserted
