TIMKEN NU326EMA Bearing

TIMKEN NU326EMA Cylindrical Roller Bearings | 130x280x58mm

Also known as : NU326EMA

  • Inside Diameter: 130 mm
  • Outside Diameter: 280 mm
  • Width: 58 mm
  • Basic dynamic load rating: 701 kN
  • Basic static load rating: 753 kN

Inquire Now

TIMKEN NU326EMA Bearing

TIMKEN NU326EMA Bearing details

Bearing Number NU326EMA
Brand TIMKEN
Type Cylindrical roller bearings
Design Units METRIC
Bearing Weight 18.20 Kg
40.100 lb
Type NU
Tapered Bore N
d - Bore 130 mm
5.1181 in
D - Outer Diameter 280 mm
11.0236 in
C - Inner Ring Width 58.000 mm
2.2835 in
B - Outer Ring Width 58.000 mm
2.2835 in
C0 - Static Radial Rating 753000 N
169000 lbf
C - Dynamic Radial Rating1 701000 N
158000 lbf
Reference Thermal Speed Rating (Grease) 2000
Reference Thermal Speed Rating (Oil)2 2300
Cg - Geometry Factor3 0.1065
R - Inner Ring "To Clear" Radius4 3.000 mm
0.100 in
r - Outer Ring "To Clear" Radius5 3.000 mm
0.100 in
da - Inner Ring Backing Diameter 160.000 mm
6.300 in

1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.

As TIMKEN bearing distributor, Nodes bearings have TIMKEN NU326EMA bearings in stock.

TIMKEN NU326EMA bearing cross reference

NSK NU326 bearing
130mm x 280mm x 58mm
FAG NU326-E-XL-TVP2 bearing
130mm x 280mm x 58mm
TIMKEN NJ2226EMA bearing
130mm x 230mm x 64mm
TIMKEN NJ226EMA bearing
130mm x 230mm x 40mm
TIMKEN NU2226EMA bearing
130mm x 230mm x 64mm
TIMKEN NU226EMA bearing
130mm x 230mm x 40mm
TIMKEN NJ326EMA bearing
130mm x 280mm x 58mm
