Bearing Number Brand Principal Dimensions Type
UC328D1NSKshaft size:140mm, Bolt size:M33, Total lenght:620mmbearing units
UCX05D1NSKshaft size:25mm, Bolt size:M14, Total lenght:159mmbearing units
UCX06D1NSKshaft size:30mm, Bolt size:M14, Total lenght:175mmbearing units
UCX07D1NSKshaft size:35mm, Bolt size:M14, Total lenght:203mmbearing units
UCX08D1NSKshaft size:40mm, Bolt size:M16, Total lenght:222mmbearing units
UCX09D1NSKshaft size:45mm, Bolt size:M16, Total lenght:222mmbearing units
UCX10D1NSKshaft size:50mm, Bolt size:M16, Total lenght:241mmbearing units
UCX11D1NSKshaft size:55mm, Bolt size:M20, Total lenght:260mmbearing units
UCX12D1NSKshaft size:60mm, Bolt size:M20, Total lenght:286mmbearing units
UCX13D1NSKshaft size:65mm, Bolt size:M20, Total lenght:286mmbearing units
UCX14D1NSKshaft size:70mm, Bolt size:M22, Total lenght:33mmbearing units
UCX15D1NSKshaft size:75mm, Bolt size:M22, Total lenght:330mmbearing units
UCX16D1NSKshaft size:80mm, Bolt size:M22, Total lenght:381mmbearing units
UC201D1NSKshaft size:12mm, Bolt size:M10, Total lenght:127mmbearing units
UC202D1NSKshaft size:15mm, Bolt size:M10, Total lenght:127mmbearing units
UC203D1NSKshaft size:17mm, Bolt size:M10, Total lenght:127mmbearing units
UC204D1NSKshaft size:20mm, Bolt size:M10, Total lenght:127mmbearing units
UC205D1NSKshaft size:25mm, Bolt size:M10, Total lenght:140mmbearing units
UC206D1NSKshaft size:30mm, Bolt size:M14, Total lenght:165mmbearing units
UC207D1NSKshaft size:35mm, Bolt size:M14, Total lenght:167mmbearing units
UC208D1NSKshaft size:40mm, Bolt size:M14, Total lenght:184mmbearing units
UC209D1NSKshaft size:45mm, Bolt size:M14, Total lenght:190mmbearing units
UC210D1NSKshaft size:50mm, Bolt size:M16, Total lenght:206mmbearing units
UC211D1NSKshaft size:55mm, Bolt size:M16, Total lenght:219mmbearing units
UC212D1NSKshaft size:60mm, Bolt size:M16, Total lenght:241mmbearing units
UC213D1NSKshaft size:65mm, Bolt size:M20, Total lenght:265mmbearing units
UC201D1NSKshaft size:12mm, Bolt size:M10, Total lenght:127mmbearing units
UC202D1NSKshaft size:15mm, Bolt size:M10, Total lenght:127mmbearing units
UC203D1NSKshaft size:17mm, Bolt size:M10, Total lenght:127mmbearing units
UC204D1NSKshaft size:20mm, Bolt size:M10, Total lenght:127mmbearing units
UC205D1NSKshaft size:25mm, Bolt size:M10, Total lenght:140mmbearing units
UC206D1NSKshaft size:30mm, Bolt size:M14, Total lenght:165mmbearing units
UC207D1NSKshaft size:35mm, Bolt size:M14, Total lenght:167mmbearing units
UC208D1NSKshaft size:40mm, Bolt size:M14, Total lenght:184mmbearing units
UC209D1NSKshaft size:45mm, Bolt size:M14, Total lenght:190mmbearing units
UC210D1NSKshaft size:50mm, Bolt size:M16, Total lenght:206mmbearing units
UC211D1NSKshaft size:55mm, Bolt size:M16, Total lenght:219mmbearing units
UC212D1NSKshaft size:60mm, Bolt size:M16, Total lenght:241mmbearing units
