INA NKXR15-XL Bearing

INA NKXR15-XL combined needle bearings | 15x24x23mm

Also known as : NKXR15-XL

  • Inside Diameter: 15 mm
  • Outside Diameter: 24 mm
  • Width: 23 mm
  • Basic dynamic load rating: 14.4 kN
  • Basic static load rating: 28.5 kN

Inquire Now

INA NKXR15-XL Bearing

INA NKXR15-XL Bearing details

Number NKXR15-XL
Type Needle roller bearings
Needle roller/axial cylindrical roller bearings

Fw 15 mm
D 24 mm
C 23 mm  Tolerance: 0/-0,25
C1 9 mm  Tolerance: 0/-0,2
C2 6,5 mm
D1 max 28,1 mm
da 23,7 mm
dw 15 mm  Tolerance: E8
ra max 0,3 mm
rmin 0,3 mm
m 42 g  Mass
Cr 12100 N  Basic dynamic load rating, radial
C0r 12700 N  Basic static load rating, radial
Ca 14400 N  Basic dynamic load rating, axial
C0a 28500 N  Basic static load rating, axial
Cur 2320 N  Fatigue limit load, radial
Cua 4000 N  Fatigue limit load, axial
nG 13000 1/min  Limiting speed
nB 6500 1/min  Reference speed
  IR12X15X16-XL  Suitable inner ring

As INA bearing distributor, Nodes bearings have INA NKXR15-XL Needle roller/axial cylindrical roller bearings in stock. NKXR15-XL is axial component, single direction, to DIN 5429, without end cap, for oil lubrication.
