INA NX15-Z-XL Bearing

INA NX15-Z-XL combined needle bearings | 15x24x28mm

Also known as : NX15-Z-XL

• Inside Diameter: 15 mm
• Outside Diameter: 24 mm
• Width: 28 mm
• Basic dynamic load rating: 5.6 kN
• Basic static load rating: 10.4 kN

Inquire Now

INA NX15-Z-XL Bearing

Number	NX15-Z-XL
Type	Needle roller bearings Needle roller/axial ball bearings
Fw	15 mm
D	24 mm
C	28 mm	Tolerance: 0/-0,25
2)		Mounting dimensions Snap ring in outer ring
C1	8 mm
C2	12,2 mm
D1	26,5 mm
da	19 mm
dw	15 mm	Tolerance: E8
ra max	0,3 mm
rmin	0,3 mm
m	48 g	Mass
Cr	12100 N	Basic dynamic load rating, radial
C0r	12700 N	Basic static load rating, radial
Ca	5600 N	Basic dynamic load rating, axial
C0a	10400 N	Basic static load rating, axial
Cur	2320 N	Fatigue limit load, radial
Cua	460 N	Fatigue limit load, axial
nG	8000 1/min	Limiting speed
	IR12X15X16-XL	Suitable inner ring
	WR24, SW24	Suitable snap rings WR and SW

As INA bearing distributor, Nodes bearings have INA NX15-Z-XL Needle roller/axial ball bearings in stock. NX15-Z-XL is single direction axial component, for grease lubrication.
