INA NX30-Z-XL Bearing

INA NX30-Z-XL combined needle bearings | 30x42x30mm

Also known as : NX30-Z-XL

• Inside Diameter: 30 mm
• Outside Diameter: 42 mm
• Width: 30 mm
• Basic dynamic load rating: 11.7 kN
• Basic static load rating: 28 kN

Inquire Now

INA NX30-Z-XL Bearing

Number	NX30-Z-XL
Type	Needle roller bearings Needle roller/axial ball bearings
Fw	30 mm
D	42 mm
C	30 mm	Tolerance: 0/-0,25
2)		Mounting dimensions Snap ring in outer ring
C1	10 mm
C2	14,2 mm
D1	45,1 mm
da	36,5 mm
dw	30 mm	Tolerance: E8
ra max	0,3 mm
rmin	0,3 mm
m	130 g	Mass
Cr	25500 N	Basic dynamic load rating, radial
C0r	36000 N	Basic static load rating, radial
Ca	11700 N	Basic dynamic load rating, axial
C0a	28000 N	Basic static load rating, axial
Cur	6300 N	Fatigue limit load, radial
Cua	1230 N	Fatigue limit load, axial
nG	4300 1/min	Limiting speed
	IR25X30X20-XL	Suitable inner ring
	WR42, SW42	Suitable snap rings WR and SW

As INA bearing distributor, Nodes bearings have INA NX30-Z-XL Needle roller/axial ball bearings in stock. NX30-Z-XL is single direction axial component, for grease lubrication.
