INA NATV30 Bearing

INA NATV30 Yoke type track rollers

Also known as : NATV30, NART30VR

  • Inside Diameter: 30 mm
  • Outside Diameter: 62 mm
  • Width: 29 mm
  • Basic dynamic load rating: 30 kN
  • Basic static load rating: 62 kN

Inquire Now

INA NATV30 Bearing

INA NATV30 Bearing details

d 30 mm
D 62 mm
B 29 mm
C 28 mm
d2 51 mm
R 500 mm  Crowning radius
rmin 1 mm
m 481 g  Mass
Cr w 30000 N  Effective dynamic load rating as track roller (radial)
C0r w 62000 N  Effective static load rating as track roller (radial)
Cur w 8800 N  Fatigue limit load
nD G 850 1/min  Speed (with continuous operation and grease lubrication)
    Bearing with gap seals and curvature radius of R = 500 mm

As INA bearing distributor, Nodes bearings have INA NATV30 Yoke type track rollers in stock, full complement needle roller set, with axial guidance, gap seals on both sides.

INA NATV30 bearing cross reference

INA NA2206-2RSR bearing
30mm x 62mm x 20mm
INA NATR30 bearing
30mm x 62mm x 29mm
INA NATR30-PP bearing
30mm x 62mm x 29mm
INA NATV30-PP bearing
30mm x 62mm x 29mm
INA PWTR30-2RS-XL bearing
30mm x 62mm x 29mm
INA PWTR3072-2RS-XL bearing
30mm x 72mm x 29mm
INA NUTR30 bearing
30mm x 62mm x 29mm
INA NUTR3072 bearing
30mm x 72mm x 29mm
INA RNA2205-2RSR bearing
30mm x 52mm x 17.8mm
INA RSTO25 bearing
30mm x 52mm x 15.8mm
