INA NUTR1747 Bearing

INA NUTR1747 Yoke type track rollers

Also known as : NUTR1747, NURT1747R

  • Inside Diameter: 17 mm
  • Outside Diameter: 47 mm
  • Width: 21 mm
  • Basic dynamic load rating: 21.6 kN
  • Basic static load rating: 30.5 kN

Inquire Now

INA NUTR1747 Bearing

INA NUTR1747 Bearing details

d 17 mm
D 47 mm
B 21 mm
C 20 mm
d2 22 mm
r1 min 0,5 mm
rmin 1 mm
m 220 g  Mass
Cr w 21600 N  Effective dynamic load rating as track roller (radial)
C0r w 30500 N  Effective static load rating as track roller (radial)
Fr per 30500 N  Permissible dynamic radial load
F0r per 30500 N  Permissible static radial load
Cur w 3850 N  Fatigue limit load
nD G 5500 1/min  Speed (with continuous operation and grease lubrication)

As INA bearing distributor, Nodes bearings have INA NUTR1747 Yoke type track rollers in stock, full complement cylindrical roller set, with axial guidance, labyrinth seals on both sides.

INA NUTR1747 bearing cross reference

INA NA2203-2RSR bearing
17mm x 40mm x 16mm
INA NATR17 bearing
17mm x 40mm x 21mm
INA NATV17 bearing
17mm x 40mm x 21mm
INA NATR17-PP bearing
17mm x 40mm x 21mm
INA NATV17-PP bearing
17mm x 40mm x 21mm
INA PWTR17-2RS-XL bearing
17mm x 40mm x 21mm
INA PWTR1747-2RS-XL bearing
17mm x 47mm x 21mm
INA NUTR17 bearing
17mm x 40mm x 21mm
INA STO17 bearing
17mm x 40mm x 16mm
