KAYDON KB030XP0 Bearing

KAYDON KB030XP0 thin section bearings

Also known as : KB030XP0

  • Inside Diameter: 3 inches
  • Outside Diameter: 3.625 inches
  • Width: 0.3125 inches
  • Basic dynamic load rating: 933 lbs
  • Basic static load rating: 3350 lbs

Inquire Now

KAYDON KB030XP0 Bearing

KAYDON KB030XP0 Bearing details

Kaydon part number KB030XP0
Bore 3.000 inches
Outside dia. 3.625 inches
Width 0.3125 inches
Land dia. L1 3.231 inches
Land dia. L2 3.393 inches
Dynamic radial 933 lbs
Dynamic thrust 1,440 lbs
Dynamic moment 1,159 lbs
Static radial 1,340 lbs
Static thrust 3,350 lbs
Static moment 2,220 lbs
Approx. weight 0.240 lbs

As KAYDON bearings distributor, Nodes bearings have KAYDON KB030XP0 open thin section bearings in stock, Reali-Slim open bearings, KB series, Type X -- four-point contact.
