NTN 7300B Bearing

NTN 7300B bearings | 10x35x11mm

Also known as : 7300B

  • Inside Diameter: 10 mm
  • Outside Diameter: 35 mm
  • Width: 11 mm
  • Basic dynamic load rating: 9.5 kN
  • Basic static load rating: 4.6 kN

Inquire Now


NTN 7300B Bearing

NTN 7300B Bearing details

Part Number 7300B
Brand NTN
Mass 0.041 kg
Boundary dimensions (mm)
Inner dia. (d) 10
Outer dia. (D) 35
Width (B) 11
Chamfer (rs_min) 0.6
Basic load ratings (kN)
Dynamic (Cr) 9.5
Static (Cor) 4.6
Basic load ratings (kgf)
Dynamic (Cr) 970
Static (Cor) 470
Limiting speed (min-1)
Grease 22000
Oil 29000
Abutment and fillet dimensions (mm)
da min 14.5
Da max 30.5
ras max 0.6

Nodes have NTN 7300B bearings in stock. 7300B, single row angular contact ball bearing.

NTN 7300B bearing cross reference

NSK 7300B bearing
10mm x 35mm x 11mm
NSK 7300A bearing
10mm x 35mm x 11mm
NSK 7300ADB bearing
10mm x 35mm x 11mm
NSK 7300BDB bearing
10mm x 35mm x 11mm
NSK 7300ADF bearing
10mm x 35mm x 11mm
NSK 7300BDF bearing
10mm x 35mm x 11mm
NSK 7300BDT bearing
10mm x 35mm x 11mm
NTN 7000 bearing
10mm x 26mm x 8mm
NTN 7200 bearing
10mm x 30mm x 9mm
NTN 7200B bearing
10mm x 30mm x 9mm
NTN 7300 bearing
10mm x 35mm x 11mm

NTN angular contact ball bearings
